Amerisolar - MONOCRYSTALLINE CRYSTALLINE AS-6M18
MECHANICAL CHARACTERISTICS
- Cell type: Monocrystalline
- Number of cells: 36
- Module dimensions: 770x730x30mm
- Weight: 5.69kg
- Front Cover: 3.2mm temperd glass
- Frame: Anodized aluminu, alloy
- Junction box: IP65
- Cable: Length can be customized
- Connector: MC4 Compatible
TEMPERATURE CHARACTERISTICS:
- Nominal Operating Cell Temperature(NOCT): 45°C±2°C
- Temperature Coefficients of Pmax: -0.45%/°C
- Temperature Coefficients of Voc: -0.37%/°C
- Temperature Coefficients of Isc: 0.05%/°C
Especificaciones técnicas
ELECTRICAL CHARACTERISTICS AT STC
- Maximum Power(Pmax): 100w
- Open Circuit Voltage (Voc): 24.44v
- Short Circuit Current (Isc): 5.38A
- Voltage at Maximum Power (Vmp): 21.12v -Current at Maximum Power (Imo): 4.74A
- Module Efficiency(%): 17.79
- Operating Temperature: -40°C to +85°C
- Maximum System Voltage: 1000V DC
- Fire Resistance Rating: Class C
- Maximum Series Fuse Rating: 5A
